Low Capacity – Manual Test Stand

Series – TSB 100

This stand replaces the TSB series. This economical test stand when used in conjunction with a Mark-10 digital force gauge is an excellent choice for low capacity force measurement. The loading handle is indexable to any position in 30 degree increments and the precision ground rack in combination with adjustable guides insure smooth and controllable motion. Repetitive testing is easy with optional adjustable travel stops.

A removable base plate contains a grid of tapped holes for fixture mounting. 100lb load capacity with a maximum travel of 6 inches and a travel rate of 3 inches per lever revolution.

Note: Mark-10 digital force gauge must be ordered separately.

*3 Year Warranty

Replaces the TSB series. More rugged column- the old 1.5inx 1.5in has been replaced with a more rugged 1.5in x 3in column? Larger base size.This economical test stand when used in conjunction with a Mark-10 digital force gauge is an excellent choice for low capacity force measurement. The loading handle is indexable to any position in 30 degree increments and the precision ground rack in combination with adjustable guides insure smooth and controllable motion. Repetitive testing is easy with optional adjustable travel stops. A removable base plate contains a grid of tapped holes for fixture mounting. Maximum travel of 6″. Note: Mark-10 digital force gauge must be ordered seperately. Ships UPS 1 year warranty100lb load capacity Maximum travel of 6 nches Travel rate of 3 inches per lever revolution 3 year warranty
